Slurry pump is widely used in many fields. So there are varities of models. Then who to choose the right model. Here Ruite pump will introduce you the basis and principles to choose the right slurry pump model.
Selection basis
1. The selection type of the slurry pump must be based on liquid transportation, that is, the capacity, and usually based on the maximum flow, taking into account normal flow. When there is no maximum capacity, it is generally enough to take 1.1 times the normal flow as the maximum capacity.
2. The choice of head generally uses 5%-10% as a spare-head.
3. Understand the properties of the liquid, including the liquid medium, chemical properties (corrosiveness, pH, thermal stability, etc.) and other properties; physical properties (temperature, viscosity, particulate matter, etc.).
4. The layout of the pipeline also be required, referring to the liquid delivery height, distance and direction, also pipeline’s length material etc., so that the tube loss calculation and the volume of the steam erosion waste can be performed.
5. There is also operating operation conditions, such as altitude, ambient temperature, whether the operation of the pump is gap or continuous, whether the position of the pump is fixed or moved.
Principles of slurry pump selection
1. First of all, we must ensure the type and performance of the pump. It is necessary to meet the requirements of process parameters such as capacity, head, pressure, temperature, steam flow, and suction.
2. It must meet the characteristics requirements of the conveying medium itself.
3. In terms of machinery, high reliability, low noise, and small vibration.
4. The material of the slurry pump must meet the on -site conditions, not the more expensive the better.
5. For slurry pumps that transport corrosive medias, the wear parts should be corrosive-resistance.
6. For slurry pumps that transport flammable and explosive, toxic or precious media, the shaft seal is required to be reliable or leakless pump.
7. In terms of cost, we must comprehensively consider equipment procurement costs, operating costs, maintenance costs and management costs, and strive to be low in comprehensive costs.
8. For slurry pumps containing solid particles medium, the wet-flow parts are required to use wear -resistant materials, and the shaft seal needs to be rinsed with cleaning liquid when necessary
Welcome to contact Ruite pump to get the right slurry pump model for your site.
